Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5
Black
Mês do Consumidor
APROVEITE!
32%
Desconto Extra
875
Vendidos
  • Novo
  • 12 meses de garantia

Placa Mãe Gigabyte Z790M Aorus Elite, Chipset Z790, Intel LGA 1700, mATX, DDR5

CÓD: Z790M AORUS ELITE
Vendido por: TerabyteShop
Pronta entrega

De: R$ 3.199,90 por:

R$ 1.849,99

à vista com 15% de desconto no boleto ou pix

R$ 2.176,46 12x de R$ 181,37 sem juros no cartão ou em 6x sem juros + Frete Grátis

visa mastercard amex diners hipercard elo
Crédito - em até 12x sem juros
  • 1x de R$ 2.176,46 s/juros + Frete Grátis*
  • 2x de R$ 1.088,23 s/juros + Frete Grátis*
  • 3x de R$ 725,49 s/juros + Frete Grátis*
  • 4x de R$ 544,12 s/juros + Frete Grátis*
  • 5x de R$ 435,29 s/juros + Frete Grátis*
  • 6x de R$ 362,74 s/juros + Frete Grátis*
  • 7x de R$ 310,92 s/juros*
  • 8x de R$ 272,06 s/juros*
  • 9x de R$ 241,83 s/juros*
  • 10x de R$ 217,65 s/juros*
  • 11x de R$ 197,86 s/juros*
  • 12x de R$ 181,37 s/juros*
* Para pagamentos via MercadoPago

O QUE ESSA MÁQUINA RODA?

PLACA MÃE GIGABYTE Z790M AORUS ELITE, CHIPSET Z790, INTEL LGA 1700, MATX, DDR5

Com as rápidas mudanças tecnológicas, a GIGABYTE sempre segue as últimas tendências e fornece aos clientes recursos avançados e tecnologias mais recentes. As placas-mãe GIGABYTE são equipadas com solução de energia atualizada, os mais recentes padrões de armazenamento e excelente conectividade para permitir desempenho otimizado para jogos.

B560M-PLUS

Z590

PERSONALIZAÇÃO

As placas-mãe GIGABYTE agrupam vários softwares úteis e intuitivos para ajudar os usuários a controlar todos os aspectos da placa-mãe e fornecer efeitos de iluminação personalizáveis ​​com estética excepcional para se adequar à sua personalidade única.

CONECTIVIDADE

As placas-mãe GIGABYTE permitem a melhor experiência de conexão com velocidades incríveis de transferência de dados através da próxima geração de rede e conectividade de armazenamento.

Z590

Z590

DESIGN TÉRMICO EXCEPCIONAL

O desempenho inigualável das placas-mãe GIGABYTE é garantido por um design térmico inovador e otimizado para garantir a melhor estabilidade de CPU, Chipset, SSD e baixas temperaturas sob carga total de aplicativos e desempenho de jogos.

Marca:
Gigabyte

Modelo:
Z790M Aorus Elite

CPU:
LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™, Pentium® Gold and Celeron® Processors
L3 cache varies with CPU

Chipset:
Intel® Z790 Express Chipset

Memory:
Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 memory modules
4 x DDR5 DIMM sockets supporting up to 192 GB (48 GB single DIMM capacity) of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Profile (XMP) memory modules

Onboard Graphics:
Integrated Graphics Processor-Intel® HD Graphics support:
1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
* Support for HDMI 2.0 version and HDCP 2.3.
1 x DisplayPort, supporting a maximum resolution of 4096x2304@60
* Support for DisplayPort 1.2 version and HDCP 2.3

Audio:
Realtek® ALC1200 CODEC
High Definition Audio
2/4/5.1/7.1-channel
* You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.
Support for S/PDIF Out

LAN:
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)

Expansion Slots:
CPU:
1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.
Chipset:
1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x4 (PCIEX4)

Storage Interface:
CPU:
1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU)
Chipset:
1 x M.2 connector (Socket 3, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
6 x SATA 6Gb/s connectors

USB:
Chipset:
1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2x2 support
1 x USB Type-C® port with USB 3.2 Gen 2 support, available through the internal USB header
1 x USB 3.2 Gen 2 Type-A port (red) on the back panel
Chipset+2 USB 2.0 Hubs:
6 x USB 3.2 Gen 1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
Chipset+2 USB 2.0 Hubs:
8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)

Internal I/O Connectors:
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
1 x CPU fan header
1 x water cooling CPU fan header
3 x system fan headers
1 x system fan/water cooling pump header
2 x addressable LED strip headers
2 x RGB LED strip headers
3 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x front panel header
1 x front panel audio header
1 x USB Type-C® header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
2 x USB 2.0/1.1 headers
2 x Thunderbolt™ add-in card connectors
1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
1 x serial port header
1 x reset button
1 x Q-Flash Plus button
1 x Clear CMOS button
1 x reset jumper

Back Panel Connectors:
1 x USB Type-C® port, with USB 3.2 Gen 2x2 support
1 x USB 3.2 Gen 2 Type-A port (red)
4 x USB 3.2 Gen 1 ports
4 x USB 2.0/1.1 ports
1 x HDMI 2.0 port
1 x DisplayPort
1 x RJ-45 port
1 x optical S/PDIF Out connector
2 x audio jacks

I/O Controller:
iTE® I/O Controller Chip

H/W Monitoring:
Voltage detection
Temperature detection
Fan speed detection
Water cooling flow rate detection
Fan fail warning
Fan speed control
* Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install.

BIOS:
1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features:
Support for GIGABYTE Control Center (GCC)
* Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
Support for Q-Flash
Support for Q-Flash Plus
Support for Smart Backup

Form Factor:
Micro ATX Form Factor; 24.4cm x 24.4cm
